9306C Pump Flanged M220 Inlet Flanged M220 Outlet
HM1C Hydraulic Motor Recommended Hydraulic Flow 11-13gpm
Max Flow:207gpm
Max Pressure:127gpm
Cast Iron Housing
- Hydraulic motor drive (for open center, closed center and load-sensing systems)
- Max. fluid temperature: 140°F/60°C
- Impeller: Nylon
- Motor: internal gear gerotor
- Hydraulic ports: 1⁄2" NPT inlet, 3⁄4" NPT outlet
- Max. motor psi: 3000 (bar: 207)
- Pump seals: Viton Ceramic
- Hydraulic motor seal: double-lip Teflon®
- Weight: 33 lbs./15 kg
For Flanged Connections You Will Also Need: BG-UFC0200 for the inlet and 2" Full port BG-UFC0200 Flange Clamp and Lipped Gasket for the pump outlet or FC220 Worm Gear glange clamps along with 200G gaskets
9306 Pumps Parts Breakdown
