The 1″- 3″ High-Flow Dura-Meter™ is made of impact resistant Lexan™ faceplate, so it holds up to the toughest treatment. It can also can withstand impacts common in the agricultural market and beyond. Made with 100% moisture-sealed circuitry, the meter is impervious to water intrusion.
The 1″-3″ High-Flow meter can be calibrated to achieve + / – 0.5% accuracy and significantly reduce Straight Inlet / Outlet requirements. The (2) 9V batteries provide power that allows you to stay in the field longer. It is over-molded with Santoprene and filled with gel, so the face-plate has improved shock resistance.
The 1″-3″ High-Flow Dura-Meter™ uses an industry leading menu driven backlit display, so it is the easiest of all chemical meters on the market to use in all light conditions. Also, it is plumbed both for in-line and 90 degree applications, adding to its versatility. In addition to the rich features, a 2 Year Maintenance Program and warranty come standard. It is available with EPDM, Silicone, and Viton® seals.
Features Benefits
-Intuitive menu-driven backlit display
-Impact resistant Lexan™ faceplate
-Accuracy +/- 0.5% with manual field calibration
-Full port with industry standard manifold M220 or M300 flanges
-Works with non-conductive material
-Counts flow in either direction
-Includes a 2-year Warranty & Maintenance Program
Operating Temp: 32°F to 140°F
Flow Rate: 2″ = 40 to 300 or 3″ = 80 to 700 GPM
Size / Connection: 2″ M220 Flange or 3″ M300 Flange
Meter Accuracy: + / – 0.5%
Backlit Display: Yes
Meter Type / Style: Paddlewheel
Body Materials: GF Polypropylene; EPDM or Viton® Seals
